| Pioneer
LineUPS - Uninterruptible
Power Systems |
| |
|
| Model:
4KVA
3.2 KW |
Base
Price US |
| AC
INPUT |
Input
ACV & Circuit Breaker requirements - standard hardwire
connection |
| Model
# UPS 4-120 |
120VAC |
50A |
$5,320.00 |
| Model
# UPS 4-208 |
208VAC |
30A |
$5,320.00 |
| Model
# UPS 4-240 |
240VAC |
30A |
$5,320.00 |
Line
Cord (optional)
/see install manual
for circuit breaker size |
120VAC |
5-50P |
|
| 208VAC |
L6-30,
L14-30 |
|
| 240VAC |
L6-30,
L14-30 |
|
| Input
Voltage Window |
+15%,
-20% of nominal VAC Input @ full load / +15%, -40% of nominal
VAC Input @ 50% load |
| Frequency |
60
HZ |
| Power
Factor |
.98 |
|
| UNIT |
| Dim
UPS
HxWxD (in.) |
36.75
x 17.5 x 21.5 |
| Dim
Battery Cab
HxWxD (in.).
N/A
|
| Weight
lbs. UPS |
442
w/battery |
| Weight
lbs. Battery Cab.
N/A |
| Efficency |
91% |
| BTU's
HR/Kw |
1080/.316 |
| Noise
Attenuation |
120db
common mode, 60db transverse (normal) mode |
| Isolation |
Output
is completely isolated from commercial power with less than
1 pf effective capacitive coupling primary to secondary. Secondary
has neutral to ground bond, qualifying as a separately derived
power source. |
| Surge
Protection |
6000
volts are suppressed to safe levels per ANSI/IEEE C62.41 -
1997 category A & B waveforms |
| Operating
Temperature |
0°
to 40° C (32° to 104° F) |
| Relative
Humidity |
0
to 95% without condensation |
| High
Altitude Operation |
Max.
altitude 10,000 ft - de-rate 1° C off max operating temp
per 1000 ft. about sea level |
| Agency
Approvals |
UL
1778, cUL |
| User
Interface |
Keypad
w/LCD display, RS232 serial communications, internal dial
in modem, dry contacts |
| Events
Monitored |
Sags,
Surges, Frequency Shifts, Voltage Spikes and Glitches are
recorded and time/date stamped |
|
|
| AC
OUTPUT |
| Output
ACV-Hardwire |
120
/ 208 / 220 / 230 / 240 |
| Output
Receptacles |
Optional
(All types available - contact factory) |
| Output
Waveform |
Computer
grade sine wave output power with less than 5% total harmonic
distortion @ rated kw load. Sine wave correcting regardless
of input voltage THD |
| Regulation |
±3%
voltage regulation |
| Load
Compatible |
Guaranteed
compatible with all loads including power factor corrected. |
| Overload |
150%
surge capability, overload alarm 101% load to 125% load for
10 min. before shutdown. Greater than 125% the system will
shutdown in 5 seconds |
| Output
Protection |
Output
ferroresonant transformer provides inherent current limiting
protection |
| DC
& INVERTER |
| Nominal
DC Voltage |
48VDC |
| Charger
Amps |
8A |
| Runtime
(Full Load/Half Load) |
10
min/25 min |
| Sound
Level |
52dBA |
| *Specifications
subject to change without notice |
|
