PoweRide RTD


Model: 500VA 500W
Base Price US

60Hz 3 Phase
ACV Input and
Over-current
Protection
Requirements




(Use fuses only)

 208y/120
10A

240 delta
10A

480y/277
10A

480 delta
10A

380y/220
10A

400y/230
10A

415y/240
10A

200 delta
10A

Input +15%, -20% of nom. VAC input @ full load: +15%, -40% of nom. VAC input @ 50% load
Output ACV 1 phase output. Same as input voltage -- or any voltage as option
Regulation + / -3% output regulation
Noise Attenuation: 120db common mode, 60db transerse (normal mode) Noise Attenuation.
Isolation Complete isolation from utility power. Less than 2pf effective capacitive coupling (primary/secondary).
Surge 6000 volts are suppressed to safe levels per ANSI/IEEE C62.41 - 1997 category A & B waveforms
Temperature 0° to 50° C, 0% to 94% relative humidity operating range
High Altitude Max. altitude 10,000 ft - de-rate 1° C off max operating temp per 1000 ft. above sea level

Overload  Inherent overload protection-immediate recovery when overload removed.
Load  Guaranteed Compatible with all loads
Dimensions
Depth 17"
Width 17"
Height 22"
Specifications subject to change without notice
