Pioneer Power Conditioners
		Model: 10KVA 8KW Base Price US AC INPUT Input ACV & Circuit Breaker requirements - standard connection Model # PPC 8-208 208VAC 70A $6,450.00 Model # PPC 8-240 240VAC 60A $6,450.00 Input Voltage Window +15%, -30% of nominal VAC Input @ full load / +15%, -40% of nominal VAC Input @ 50% load Frequency 60 HZ Input THD 5% or less
UNIT Dimension* HxWxD (in.) 19.25 x 17.5 x 21.5 Weight* lbs. 430 Efficiency 93% BTU's HR/Kw 2055/.602 Noise Attenuation 120db common mode, 60db transverse (normal) mode Isolation Output is completely isolated from commercial power with less than 2 pf effective capacitive coupling primary to secondary. Secondary has neutral to ground bond, qualifying as a separately derived power source. Surge Protection 6000 volts are suppressed to safe levels per ANSI/IEEE C62.41 - 1997 category A & B waveforms Operating Temperature 0° to 40° C (-4° to 104° F) Relative Humidity 0 to 95% without condensation High Altitude Operation Max. altitude 10,000 ft - de-rate 1° C off max operating temp per 1000 ft. above sea level Agency UL 1778, cUL listed User Interface Keypad w/LCD display, RS232 serial communications, dial in modem		AC OUTPUT Output AC Voltage  120 / 208 / 240 Output Receptacles  Optional Output Waveform Computer grade sine wave output power into resistive load. Regulation ±1% voltage regulation Load Compatible Guaranteed compatible with all loads Overload 150% surge capability, overload alarm 101% load to 125% load for 10 min. before shutdown. Greater than 125% the system will shutdown in 5 seconds *Specifications subject to change without notice CLICK HERE For a Quote ORDER NOW!
